Adventure made easier.
Meet the Hellion 16
Closer look
The full story
A performance optimised aluminium frame
Built for performance, the Hellion 16 features a triple-butted aluminium frameset with a CNC'd chainstay yoke that’s precision engineered to take big hits like a champ.
The frame tubing has been deliberately crafted to balance strength (at the pressure points) with lightness (everywhere else), to ensure we don’t add unnecessary weight or hinder progress.
Threaded thru axles ramp up frame stiffness while sliding dropouts enable handing and size adjustments as little riders progress.
To top it off, we added internal cable routing because a bike this slick demands it.
The frame tubing has been deliberately crafted to balance strength (at the pressure points) with lightness (everywhere else), to ensure we don’t add unnecessary weight or hinder progress.
Threaded thru axles ramp up frame stiffness while sliding dropouts enable handing and size adjustments as little riders progress.
To top it off, we added internal cable routing because a bike this slick demands it.
A low, slack and short geometry
That’s the assignment and we understood it.
The Hellion 16 is built for performance with a geometry optimised for speed, technical acumen and confidence on the gnarly bits.
The low centre of gravity keeps them balanced in the berms while the slack head tube angle takes (some of the drama) out of descending. The short seat stays give the bike a playful responsive feel (while also making manuals just a little easier to master).
The Hellion 16 is built for performance with a geometry optimised for speed, technical acumen and confidence on the gnarly bits.
The low centre of gravity keeps them balanced in the berms while the slack head tube angle takes (some of the drama) out of descending. The short seat stays give the bike a playful responsive feel (while also making manuals just a little easier to master).
A no fuss, full gas chainset
The chainring, crankset and single speed set-up give the Hellion 16 an awesome mix of performance, safety and pedalling efficiency that you simply won’t find on other bikes this size.
Narrow wide chain teeth stop the chain from flapping and slipping and work in harmony with shortened 110m cranks for pedalling efficiency.
The single speed set up saves weight while allowing little ones to give the trail their full attention.
Narrow wide chain teeth stop the chain from flapping and slipping and work in harmony with shortened 110m cranks for pedalling efficiency.
The single speed set up saves weight while allowing little ones to give the trail their full attention.
Touchpoints that elevate control
Every one of The Helion 16’s competition level touchpoints are built to save weight without compromising on performance.
We’ve collaborated with the brilliant Ritchey Logic to deliver a perfect rail adjusted ergonomic saddle, combined with robust seat post and quick release clamp. The double butted aluminium bars are strong, light and small enough for mini rippers to keep control.
Ritchey Logic have been at the forefront of component design for the past 50 years. We’ve collaborated with them for over a decade, producing some of the best age specific components to ever grace a kids’ bike.
We’ve collaborated with the brilliant Ritchey Logic to deliver a perfect rail adjusted ergonomic saddle, combined with robust seat post and quick release clamp. The double butted aluminium bars are strong, light and small enough for mini rippers to keep control.
Ritchey Logic have been at the forefront of component design for the past 50 years. We’ve collaborated with them for over a decade, producing some of the best age specific components to ever grace a kids’ bike.
Gear ready and engineered for fast progression
The Helion 16 is designed for rider and bike progression. As they improve, you’ll find their need for a few gears increases.
We supply the Helion 16 gear-ready, with a separate mech hanger, gear routing and rear hub which allows the addition of a small ratio cassette.
This allows them to learn the fundamentals of gear shifting in a bike they’re comfortable with. And it allows you to eek out way more value from a bike that’s already designed to last a lifetime.
We supply the Helion 16 gear-ready, with a separate mech hanger, gear routing and rear hub which allows the addition of a small ratio cassette.
This allows them to learn the fundamentals of gear shifting in a bike they’re comfortable with. And it allows you to eek out way more value from a bike that’s already designed to last a lifetime.
MTB wheels that go hard
Fully sealed bearing hubs, tubeless compatible, double wall rims and optimised spoke count means these wheels rip. Because there’s no point speccing a great bike with weak wheels.
The sealed bearings keep mud, water and corrosion at bay while double wall rims give you twice the confidence on rocks and roots.
The optimised spoke count means you won’t have to worry about buckled wheels while thru axles make the rare times you do need to swap tyres a breeze.
The sealed bearings keep mud, water and corrosion at bay while double wall rims give you twice the confidence on rocks and roots.
The optimised spoke count means you won’t have to worry about buckled wheels while thru axles make the rare times you do need to swap tyres a breeze.
Tan walls for the win
Big adventure requires big tyres and we’re not playing around when it comes to speccing the Helion.
Whether you’re navigating mud, berms, ruts or roots, our 2.25" knobbly tyres deliver traction, control and protection.
And everyone knows that tan wall tyres just look better.
Whether you’re navigating mud, berms, ruts or roots, our 2.25" knobbly tyres deliver traction, control and protection.
And everyone knows that tan wall tyres just look better.
Light, powerful hydraulic disc brakes
At 65g, the 140mm hydraulic powered disc rotors mean business. Because sending it relies on stopping it. With partially rounded edges and 6 bolts you’re also guaranteed extra safety even when you’ve stopped.
The brake levers features a lightweight, and most importantly, adjustable action to accommodate small hands.
We also made the decision to replace the brake fluid with mineral oil. It’s less corrosive and a bit kinder on the environment.
The brake levers features a lightweight, and most importantly, adjustable action to accommodate small hands.
We also made the decision to replace the brake fluid with mineral oil. It’s less corrosive and a bit kinder on the environment.
Specs and Geometry
Specification
| STANDOVER HEIGHT | 43.5CM |
| FRAME | TRIPLE BUTTED AL6061 INTERNAL CABLING, FORGED D/OUTS |
| FORK | RIGID DISC AL6061, 12MM THRU AXLE, FORGED D/OUTS |
| STEERER | TUBE AL6061 |
| CRANKS | SAMOX 110MM DIRECT MOUNT, NQF |
| PEDALS | ER RESIN PLATFORM, SEALED CARTRIDGE BEARING |
| BOTTOM BRACKET | SAMOX 24MM EXTERNAL CUP, SEALED CARTRIDGE BEARING |
| RIMS | 16 x 24H, DOUBLE WALLED AL6061, TUBELESS COMPATIBLE |
| REAR HUB | STRAIGHT PULL DISC, 12x142 THRU AXLE, 24H |
| FRONT HUB | STRAIGHT PULL DISC, 12x100MM THRU AXLE, 24H |
| AXLES | 12MM AL7075 THRU AXLES, F + R |
| CHAIN | KMC X10 |
| CHAINRING | CNC'D STEEL 30T NARROW WIDE |
| WEIGHT | 6.8KGS W/O PEDALS |
| REAR CASSETTE | ER SINGLE SPEED KIT |
| BRAKES | PROMAX DSK926 HYDRAULIC JR, 140MM ROTORS |
| LEVERS | PROMAX DSK926 JR |
| FRONT TYRE | VEE CROWN GEM 16x2.25", 27TPI WB, SKINWALL |
| REAR TYRE | VEE CROWN GEM 16x2.25", 27TPI WB, SKINWALL |
| HEADSET | 1 1/8" CARTRIDGE BEARING, CONVENTIONAL |
| STEM | RITCHEY OS FORGED AL6061, 35MM REACH |
| BARS | 480MM RITCHEY OS AL6061, 18MM RISE |
| GRIPS | ER SOFT TOUCH MUSHROOM 100MM |
| SEAT POST | RITCHEY 27.2MM x 185MM |
| SADDLE | ER WINGED, RAILED |
| SEAT CLAMP | ER BOLT, 31.8MM |
| SPEC NOTICE | Every effort has been made to ensure accuracy throughout this website. However, Early Rider reserves the right to change prices and bike specifications without prior notice |
Geometry
| A | Wheelbase | 720mm |
| B | Head Angle | 68° |
| C | Seat Tube Length | 210mm |
| D | Chainstay Length | 280mm |
| E | Seat Tube Angle | 71° |
| F | Standover Height | 420mm |
| G | Top Tube Length | 399mm |
| H | Head Tube Length | 90mm |
| I | Stack | 346mm |
| J | Reach | 280mm |
| K | Fork Length | 266mm |
