Hellion X20



Regular price $1,899.00 clear all

Out of stock

Thanks! We will notify you when this product becomes available.

Hellion X20

Hellion X20
Hellion X20
Hellion X20
Hellion X20

Hellion X Lil Shredder

If you're introducing your young prodigy to the bike park, look no further. Developed in collaboration with Lil Shredder, the pioneers of the junior competitive scene, this bikes cashes in on an unrivalled 9 year legacy. Raced and refined by the who's who of the best young riders tearing up the very toughest terrain Whistler has to offer; this bike will see your little shredder progresses faster than you could have imagined

The frameset - built from a combination of 6061 and 6066 tubing and fully CNC’d linkage plates and dropouts ensure incredible build strength and quality. Welded by one of the best frame makers in the business. The frame is versatile, it can be run with 16” or 20” wheels by replacing the rear dropouts. It features 3.5” of travel with 16” wheels and 4” with the 20” setup. Customised RST spex forks give 100mm of plush and reliable front wheel travel. The unique DNM shock boasts all the features you need for a bike like this, rebound adjust and a pedal platform to make pedaling a bit easier on the legs.

The balance of the component choice mimics our hellion 20 trail bikes; tubeless compatible wheelset with folding bead Vee Crown Gem tyres (& space in the frame up to 2.4”). A 10 speed one by drivetrain with a notable 11-36T gear range, short reach stem, butted 560mm riser bars, lock on grips and some of the lightest actuating hydraulic brakes available... a very serious piece of kit.

ASSEMBLY INSTRUCTIONS:

Your bike will arrive carefully packaged and boxed with the rear wheel attached. The front wheel will need attaching using the axle supplied. The handlebar will be ziptied to the top tube, simply remove the bars and all packaging and attach to the stem. Add the saddle and adjust to the required height. Then simply add the pedals. You will be emailed an unboxing video with full instructions. Please retain your manual.

Trail

5/5

Adventure

4/5

Urban

2/5

0
1
2
3
4
5
6
7
8
9
10
11
70
80
90
100
110
120
130
140
150
160cm
2 - 4
2 - 4
2 - 4
2 - 4
2 - 4
2.5 - 5
3.5 - 6
5.5 - 8
8 - 11
2.5 - 5
3.5 - 6.5
5.5 - 8
8 - 11
3.5 - 6
5.5 - 8
8 - 11
4 - 8
7.5 - 11
70 - 80
72.5 - 82.5
80 - 85
87.5 - 102.5
87.5 - 102.5
92.5 - 110
102.5 - 120
117.5 - 135
130 - 150
92.5 - 110
102.5 - 120
117.5 - 135
130 - 150
100 - 120
117.5 - 135
130 - 150
100 - 135
125 - 150

INSIDE LEG

53CM

FRAME

BUTTED ALLOY FRAME, 95MM TRAVEL

REAR SHOCK

DNM AO-38RC, 152X25.4MM REBOUND ADJUST, PEDAL PLATFORM

FORKS

RST SPEX 100MM TRAVEL, 15MM BOLT THRU AXLE

CRANKS

SAMOX 127MM DIRECT MOUNT

PEDALS

SDG SLATER 90 PEDALS, BLACK

BOTTOM BRACKET

SAMOX EXTERNAL CUP, THREADED, SEALED CARTRIDGE BEARING

RIMS

20 X 28H DOUBLE WALLED AL6061, PINNED, TUBELESS COMPATIBLE

REAR HUB

CNC'D STRAIGHT PULL AL6061, 12x142 THRU AXLE

FRONT HUB

CNC'D STRAIGHT PULL AL6061, 15x100MM THRU AXLE

AXLES

THRU AXLES AL7075, 15MM FRONT, 12X142MM REAR (1.0P)

CHAIN

KMC X10

CHAINRING

SAMOX OFFSET NARROW WIDE, STEEL, 30T

REAR CASSETTE

SUNRACE CSMX0 11-36T, 10SPD



CLICK HERE TO VIEW THE USER MANUAL

WEIGHT

10.15KGS W/O PEDALS

SHIFTER

SHIMANO DEORE SL-M6000 RAPIDFIRE RH 10SPD (I-SPEC II)

DERAILLEUR

SHIMANO ZEE M640 SS 10SPD 11-36

BRAKES

SHIMANO DEORE BR-MT500, 160MM RT66 ROTORS

LEVERS

SHIMANO DEORE BL-MT501

FRONT TYRE

VEE CROWN GEM SKINWALL 20x2.25", 72TPI FOLDING, TR

REAR TYRE

VEE CROWN GEM SKINWALL 20x2.25", 72TPI FOLDING, TR

HEADSET

ER CONVENTIONAL HEADSET, 1 1/8” CARTRIDGE BEARING

STEM

RITCHEY OS FORGED AL6061, 35MM REACH

BARS

560MM RITCHEY OS DOUBLE BUTTED AL6061, 18MM RISE

GRIPS

ER LOCK ON KRATON 92MM

SEAT POST

RITCHEY, 30.9MM x 225MM, AL2014

SADDLE

SDG FLY JR, BLACK

SEAT CLAMP

PROMAX  QR, 34.9MM
