Specs and Geometry

Specification
STANDOVER HEIGHT16.1"
FRAMEHAND BRUSHED AL6061, FORGED SLIDING DROP OUTS
FORKHAND BRUSHED AL6061, FORGED DROP OUTS
STEERERTUBE AL6061
CRANKSCRUX CNC'D AL6061, 90MM
PEDALSRESIN PLATFORM, STUDDED, CARTRIDGE BEARING
BOTTOM BRACKETCRUX EXTERNAL CUP, SEALED CARTRIDGE BEARING
RIMS16 x 24H, DOUBLE WALLED AL6061
REAR HUBFOUR-BEARING CASSETTE FREE HUB, CNC'D AL6061
FRONT HUBCNC'D AL6061, CARTRIDGE BEARING
AXLESALLOY 12MM BOLT THRU
CHAINKMC X9
FRONT SPROCKETCNC'D AL6061, 26T
WEIGHT14.0 LBS WITHOUT PEDALS
REAR SPROCKETCNC'D AL7075, 15T
BRAKESCRUX HYDRAULIC DISC BRAKE WITH 140MM ROTORS
LEVERSCRUX HYDRAULIC SHORT REACH
FRONT TYREKENDA BOOSTER 16x2.2", 30TPI WB
REAR TYREKENDA BOOSTER 16x2.2", 30TPI WB
HEADSET1 1/8” CARTRIDGE BEARING, CONVENTIONAL
STEMFORGED AL6061, 35MM REACH
BARS500MM DOUBLE BUTTED AL6061, 1" RISE, 19MM GRIP
GRIPSER 19MM SOFT TOUCH MUSHROOM 100MM
SEAT POSTAL6061, 25.4MM x 195MM
SADDLEBLACK WING COMBO
SEAT CLAMPER QUICK RELEASE, 28.6MM
SPEC NOTICEEvery effort has been made to ensure accuracy throughout this website. However, Early Rider reserves the right to change prices and bike specifications without prior notice
Geometry
AWheelbase29.5"
BHead Angle67°
CSeat Tube Length8.3"
DChainstay Length11.3"
ESeat Tube Angle72°
FStandover Height16.1"
GTop Tube Length15.7"
HHead Tube Length3.5"
IStack13.8"
JReach11.2"
KFork Length10.7"

Meet the new Seeker 16

Ideal for young riders ready to take on more challenging terrain, the Seeker 16 is a rigid MTB that is designed for the next step in mountain biking. With geometry improvements like a lower bottom bracket for enhanced stability, slacker headtube angles for improved handling whilst descending and a lower standover height for easier mounting, this bike is built for confidence. The single-speed drivetrain with optimized gear ratios and short 90mm crank arms ensures smooth, efficient pedaling. Kitted out with 140mm CRUX hydraulic disc brakes, sealed bearing 16" wheels with bolt-thru axles, and grippy Kenda Booster 2.2" tires, this bike offers the performance and durability needed for off-road exploration. Reduced grip diameter ensures better control for smaller hands, making it the perfect choice for adventurous young riders.
