Specs and Geometry

Specification
STANDOVER HEIGHT 54CM
FRAMEHAND BRUSHED AL6061, FORGED SLIDING DROP OUTS
FORKRST F1RST 100MM TRAVEL AIR SUSPENSION FORK
STEERERTUBE AL6061
CRANKSCRUX 110MM DIRECT MOUNT, NARROW Q FACTOR
PEDALSER CNC'D AL6061, PLATFORM, STUDDED, CARTRIDGE BEARING
BOTTOM BRACKETCRUX 24MM EXTERNAL CUP
RIMS20 X 28H, DOUBLE WALLED TUBELESS COMPATIBLE
REAR HUBFOUR-BEARING CASSETTE FREEHUB, CNC'D AL6061
FRONT HUBCNC’D 6 BOLT DISC, AL6061, QR SKEWER
AXLESREAR: 12MM BOLT THRU, FRONT: 15MM BOLT THRU

CHAINKMC eGLIDE
CHAINRING

DIRECT MOUNT, NARROW WIDE 30T, ALLOY
WEIGHT10.2KGS W/O PEDALS
REAR CASSETTESHIMANO 9-SPEED 11-36T LINKGLIDE
BRAKESTEKTRO HYDRAULIC DISC, 160 ROTORS
LEVERSTEKTRO SHORT REACH
FRONT TYRESCHWALBE ROCKET RON 20x2.25", 67TPI FOLDING
REAR TYRESCHWALBE ROCKET RON 20x2.25", 67TPI FOLDING
HEADSET1 1/8” CARTRIDGE BEARING, CONVENTIONAL
STEMFORGED AL6061, 35MM REACH
BARS560MM DOUBLE BUTTED AL6061, 25MM RISE
GRIPSER LOCK ON KRATON 92MM
SEAT POST30.9MM

SADDLEER WING 2, RAILED
SEAT CLAMPER QR 34.9mm
DERAILLEURSHIMANO CUES 9-SPEED MECH
SPEC NOTICEEvery effort has been made to ensure accuracy throughout this website. However, Early Rider reserves the right to change prices and bike specifications without prior notice
Geometry
AWheelbase898.9mm
BHead Angle67°
CSeat Tube Length280mm
DChainstay Length340mm
ESeat Tube Angle73°
FStandover Height540mm
GTop Tube Length473.8mm
HHead Tube Length100mm
IStack487.6mm
JReach324.7
KFork Length410mm

Meet the new Charger 20

The Charger 20 is a premium 20" hardtail bike built for young riders aged 6–8 who are ready to push their trail riding further. Equipped with 100mm RST F1RST air suspension forks and a lightweight, trail-optimized frame that is dropper post ready. The Charger 20 offers outstanding control, comfort, and confidence on rough terrain. Sealed bearing wheels with bolt-thru axles deliver strength and smooth, consistent rolling, while wide Schwalbe Rocket Ron 2.25" tires ensure superior grip across mixed surfaces. The refined chain-driven drivetrain features a new 110mm chainset and a Shimano CUES 9 Speed drivetrain for improved pedal efficiency. Making the Charger 20 the perfect choice for ambitious young trail riders.

Charger 20 (pre-order)
Color
Color: Brushed Aluminium
Description
The Charger 20 is a premium 20" hardtail bike built for young riders aged 6–8 who are ready to push their trail riding further. Equipped with 100mm RST F1RST air suspension forks and a lightweight, trail-optimized frame that is dropper post ready.
SIZE OF LEG
21in
AGE
6-8years
WEIGHT
22.60lb
Seeker 20 (pre-order)
Color
Color: Brushed Aluminium
Description
The Seeker 20 is built for exploring rugged trails and off-road terrain. Continuing with the geometry up grades such a lower bottom bracket for improved stability, slacker headtube angles for precise handling and wider tire clearance this bike is made for confident riders.
SIZE OF LEG
20.1in
AGE
6-8years
WEIGHT
19.09lb

Product Main Features

Bike park optimised Geometry
20'' Wheels
Lightweight Suspension fork
Chain drive
Gears - Chain drive
Hydraulic Disc brakes

Product Specification

RST F1RST 20” air suspension forks with 100mm travel
Schwalbe Smart Sam 2.35" Tyres
Shimano 9 speed CUES drivetrain
Shimano Altus 1x8 Drivetrain
Schwalbe Rocket Ron 2.25” tires
Tektro Hydraulic Disc Brakes
