Seeker 14 (pre-order)
Description
Accessories for this bike
Specs and Geometry
Specification
| STANDOVER HEIGHT | 37CM |
| FRAME | HAND BRUSHED AL6061, FORGED DROP OUTS |
| FORK | HAND BRUSHED AL6061, FORGED DROP OUTS |
| STEERER | TUBE AL6061 |
| CRANKS | CRUX CNC'D AL6061, 80MM |
| PEDALS | RESIN PLATFORM, SEALED CARTRIDGE BEARING |
| BOTTOM BRACKET | CRUX EXTERNAL CUP, SEALED CARTRIDGE BEARING |
| RIMS | 14 x 24H, DOUBLE WALLED AL6061 |
| REAR HUB | CNC'D AL6061, 4 SEALED BEARING CASSETTE FREE HUB |
| FRONT HUB | CNC'D AL6061, SEALED CARTRIDGE BEARING |
| AXLES | ALLOY 12MM BOLT THRU |
| CHAIN | KMC X9 |
| FRONT SPROCKET | CNC'D AL6061, 26T, |
| WEIGHT | 5.9KGS WITHOUT PEDALS |
| REAR SPROCKET | CNC"D AL7075, 15T |
| BRAKES | CRUX HYDRAULIC DISC BRAKES WITH 140MM ROTORS |
| LEVERS | CRUX HYDRAULIC SHORT REACH |
| FRONT TYRE | KENDA BOOSTER 14x2.2, 30TPI WB |
| REAR TYRE | KENDA BOOSTER 14x2.2, 30TPI WB |
| HEADSET | 1 1/8” CONVENTIONAL, EXTERNAL CUP |
| STEM | FORGED AL6061, 35MM REACH |
| BARS | 440MM DOUBLE BUTTED AL6061, 22MM RISE, 19MM GRIP |
| GRIPS | ER 19MM SOFT TOUCH MUSHROOM 100MM |
| SEAT POST | AL6061, 25.4MM x 150MM |
| SADDLE | BLACK WING COMBO |
| SEAT CLAMP | ER BOLT, 28.6MM |
| SPEC NOTICE | Every effort has been made to ensure accuracy throughout this website. However, Early Rider reserves the right to change prices and bike specifications without prior notice |
Geometry

| A | Wheelbase | 661.9mm |
| B | Head Angle | 67° |
| C | Seat Tube Length | 185mm |
| D | Chainstay Length | 262mm |
| E | Seat Tube Angle | 72° |
| F | Standover Height | 370mm |
| G | Top Tube Length | 348.7mm |
| H | Head Tube Length | 90mm |
| I | Stack | 310mm |
| J | Reach | 248mm |
| K | Fork Length | 240mm |

Meet the new Seeker 14
