Hellion 16





$729.00 clear all

Hellion 16

Hellion 16
Hellion 16





Well, hello there.

Say hello to a bike that is extreme in every way. The best performance, capability and configuration in a 16" yet, it is a bike created for early riders to push the limits of what's possible, and then do it again.

It's built around the most impressive robust and lightweight frame set. Triple butted tubing and a CNC'd chain stay yoke, means there are no weak points. Precise wheel and disc alignment every time thanks to 12mm thru axles front and rear. Complete with internal cable routing to make sure everything is out of the way.

For those beginning to hit gaps, protection against casing with double walled tubeless ready rims on CNC'd hubs and straight pull spokes. Helped by a long, low and slack geometry for confidence inspiring stability and short stay, quick handling for when it gets technical.

Assured, efficient power transfer through a narrow q factor crankset with a direct mount narrow wide chainring and finished off with custom Rticthey controls and hydraulic disc brakes with some of the lightest actuation we've tested.

This is the best start to hitting the bike parks, but if you do want more, our four bearing cassette hub, 12 x 142mm drop outs, mech hanger and additional routing, mean gears are an easy option  - and with our CNC'd yoke, so are 2.6" tyres for those really riding the rough.

Riding style

Trail

5/5

Riding style

Adventure

4.5/5

Riding style

Urban

4/5

Hellion 16 aluminium pedal bike next to standover ruler
Hellion 16 bike infront of black background
Kid riding a Hellion 16 on a bern
Hellion 16 aluminium pedal bike next to standover ruler
Hellion 16 bike infront of black background
Kid riding a Hellion 16 on a bern

0
1
2
3
4
5
6
7
8
9
10
11
70
80
90
100
110
120
130
140
150
160cm
Lite
2 - 4
Classic
2 - 4
Bonsai
2 - 4
Charger 12
2 - 4
Big Foot 12
2 - 4
Belter 14
2.5 - 5
Belter 16
3.5 - 6
Belter 20
5.5 - 8
Belter 24
8 - 11
Seeker 14
2.5 - 5
Seeker 16
3.5 - 6.5
Seeker 20
5.5 - 8
Seeker 24
8 - 11
Hellion 16
3.5 - 6
Hellion 20
5.5 - 8
Hellion 24
8 - 11
HELLION X20
4 - 8
Hellion X24
7.5 - 11
Lite
70 - 80
Classic
72.5 - 82.5
Bonsai
80 - 85
Charger 12
87.5 - 102.5
Big Foot 12
87.5 - 102.5
Belter 14
92.5 - 110
Belter 16
102.5 - 120
Belter 20
117.5 - 135
Belter 24
130 - 150
Seeker 14
92.5 - 110
Seeker 16
102.5 - 120
Seeker 20
117.5 - 135
Seeker 24
130 - 150
Hellion 16
100 - 120
Hellion 20
117.5 - 135
Hellion 24
130 - 150
HELLION X20
100 - 135
Hellion X24
125 - 150

INSIDE LEG

17 INCHES

FRAME

TRIPLE BUTTED AL6061 INTERNAL CABLING, FORGED D/OUTS

FORK

RIGID DISC AL6061, 15MM THRU AXLE, FORGED D/OUTS

STEERER TUBE

AL6061

CRANKS

SAMOX 110MM DIRECT MOUNT, NQF

PEDALS

ER P1 RESIN PLATFORM, STUDDED, CARTRIDGE BEARING

BOTTOM BRACKET

SAMOX 24MM EXTERNAL CUP, SEALED CARTRIDGE BEARING

RIMS

16 x 24H, DOUBLE WALLED AL6061, TUBELESS COMPATIBLE

REAR HUB

STRAIGHT PULL DISC, 12x142 THRU AXLE,  24H

FRONT HUB

STRAIGHT PULL DISC, 15x100MM THRU AXLE, 24H

AXLES

12MM AL7075 THRU AXLES, F + R

BELT

KMC X10

CHAINRING

CNC'D STEEL 30T NARROW WIDE



CLICK HERE TO VIEW THE USER MANUAL

WEIGHT

15 POUNDS W/O PEDALS

CASSETTE

ER SINGLE SPEED KIT

BRAKES

PROMAX DSK926 HYDRAULIC JR, 140MM ROTORS

LEVERS

PROMAX DSK926 JR

FRONT TYRE

VEE CROWN GEM 16x2.25", 72TPI1 WB

REAR TYRE

VEE CROWN GEM 16x2.25", 72TPI1 WB

HEADSET

1 1/8” CARTRIDGE BEARING, CONVENTIONAL

STEM

RITCHEY OS FORGED AL6061, 35MM REACH

BARS

480MM RITCHEY OS AL6061, 18MM RISE

GRIPS

ER LOCK ON KRATON 92MM

SEAT POST

RITCHEY 27.2MM x 185MM

SADDLE

BLACK RIVETTED FAUX NUBUCK

SEAT CLAMP

ER BOLT, 31.8MM
